Model |
Description |
Laser configuration |
|
RGB V4-3 |
12W Full color laser lamp |
R600mW-638nm / G1000mW-520n / B1500mW-445nm |
|
RGB V4-5 |
20W Full color laser lamp |
R1000mW-638nm /G2000mW-520n / B2000mW-445nm |
Technical parameters:
Rated voltage: AC110V-AC230V ±10％（300W）
Rated frequency: 50Hz-60Hz
Laser source: semiconductor laser
Modulation mode: analog modulation 0-100 linear dimming
Laser color: Red 638nm, Green 520nm, Blue 445nm.
Scanning system: 20KPPS, plus or minus 25 degrees
DMX channel: 18/66 channel optional (function of each header channel, color and effect can be controlled
separately)
Control signal: nternational standard DMX-512 signal
Control mode: DMX-512 signal control, sound control, self - walk control, master slave synchronous control.
Cooling system: fan forced cooling
Working environment: indoor
Length: 350*350*160mm Weight: 11.3 kg（Four 3 W）
Length: 462*439*160mm Weight: 14.5 kg（Four 5 W）
